1972-1980 Chevy LUV Weld-On IFS | Independent Front Suspension

Why Upgrade the Factory Chevy LUV Front Suspension?

The original Chevy LUV was never designed around today’s horsepower, tire technology, braking capability or expectations for handling. Upgrading to a modern independent front suspension completely changes the personality of the truck. Scott’s Hotrods’ Chevy LUV IFS provides modern suspension geometry while opening the door to adjustable coilovers, rack-and-pinion steering, larger performance brakes and significantly improved road manners.

The result is a classic Chevy LUV that retains its unmistakable vintage mini-truck character while driving more like a modern performance vehicle. From comfortable street cruising to aggressive cornering, every component works together as a complete suspension system rather than a collection of universal parts.

Not a Mustang II Chevy LUV Front Suspension

When shopping for a Chevy LUV front suspension conversion, you’ll find plenty of universal and Mustang II-based components. Scott’s Hotrods takes a different approach.

Our IFS uses Scott’s proprietary suspension geometry with a heavy-duty one-piece crossmember constructed from 2″ x 4″ x 3/16″-wall box tubing, tubular unequal-length control arms manufactured from 1-1/8″ x .250-wall seamless DOM tubing, oversized serviceable ball joints, adjustable upper control arms and built-in anti-dive geometry. Every system is engineered as a complete performance front suspension rather than simply adapting generic components to the Chevy LUV frame.

Chevy LUV Coilover Front Suspension

The standard Scott’s Hotrods 1972-1980 Chevy LUV IFS includes Aldan American single-adjustable coilovers, giving you control over ride height and shock damping while eliminating the original front suspension arrangement. The system can be tuned for a comfortable street-driven LUV or set up for more aggressive performance driving.

Because every Chevy LUV project is different, Scott’s builds the suspension around the customer’s vehicle specifications and intended stance. Depending on the desired ride height and suspension configuration, modification of the original frame rails may be required to provide proper coilover clearance.

Rack-and-Pinion Steering for the 1972-1980 Chevy LUV

Modern suspension deserves modern steering. The Scott’s Hotrods Chevy LUV IFS replaces the original steering arrangement with a custom-narrowed rack-and-pinion steering system, providing a cleaner installation, improved steering response and a more direct connection between the steering wheel and front tires.  A Power Rack & Pinion is not an option because the track width and A-Arm Pivot Points of the Chevy LUV IFS is too narrow.

1972-1980 Chevy LUV IFS Applications

Scott’s Hotrods’ Chevy LUV Weld-On IFS is designed specifically for 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979 and 1980 Chevrolet LUV trucks. Whether you’re restoring an early Chevy LUV, building a custom mini truck or transforming one into a modern performance truck, the Scott’s IFS provides a purpose-built foundation for upgrading the front suspension, steering, brakes and stance.

Build Your Chevy LUV to Drive Like It Should

A lightweight Chevy LUV with modern suspension can be an incredibly fun truck to drive. Don’t compromise the build with an outdated front suspension or a universal crossmember that was never engineered specifically for your application. A Scott’s Hotrods 1972-1980 Chevy LUV Weld-On IFS gives your truck the modern handling, steering, braking and adjustability needed to turn an old-school mini truck into a serious street machine.

Every Scott’s Hotrods Chevy LUV IFS is built to order in Knoxville, Tennessee, using American-made materials and backed by Scott’s Hotrods’ Lifetime Craftsmanship Warranty. From a clean weekend cruiser to a slammed custom or high-horsepower performance build, we’ll configure your Chevy LUV front suspension around your truck, your stance and the way you intend to drive it.
